Russound® Sixteen-Channel Digital Amplifier

Model #: D1650

At a Glance

The Russound D1650 digital multi-channel amplifier offers the features custom installation professionals demand while offering a lighter weight, smaller chassis and more efficient Class D power. The feature-rich design of the D1650 is ideal for the demands of distributed audio systems and is also compatible with our Russound volume controls.

WarningProposition 65 Warning for California Residents
Russound® Sixteen-Channel Digital Amplifier

General Specs

Impedance>22k Ohms Line Input
Channels16
Analog Audio(RCA) Input9

General

Shipping Dimensions21.5" (W) x 9.0" (H) x 22.0" (D), (54.6 x 22.9 x 55.9 cm)
Shipping Weight28.8 lbs (13.1 kg)
Amplifier Channels16 Channels, 8 independent zones
Bridge ModeSelect Stereo or Bridge mode per zone 8 Ohm only
Frequency Response20Hz to 20kHz +1.7/-1dB at 1W output into 8 Ohms
Fuse Rating100-120V/T5A, 250V US & Canada, 220-240V/T2.5A, 250V Europe
Input Impedance>22k Ohms Line Input
Input Sensitivity600 mV for 80W @ 1 KHz 4 Ohm One Zone; 700 mV for 50W @ 1 KHz 8 Ohm One Zone
Power Output80W /Channel, 1kHz into 4 Ohms, One Zone Driven; 50W /Channel, 1kHz into 8 Ohms, One Zone Driven; 160W, 1kHz into 8 ohms, Bridge
Signal to Noise Ratio>90dB A-weighted
Speaker Connection(s)Detachable speaker terminals support up to 14awg wire
Switching DelayThree settings, 5 Seconds, 5 minutes, 10 minutes
Trigger Input(s)Bus and Zone @12VDC
Zone Line InputLine or Bus select switch per zone

Russound® Sixteen-Channel Digital Amplifier

Model #: D1650
186596
Russound

Call for Best Price

At a Glance

The Russound D1650 digital multi-channel amplifier offers the features custom installation professionals demand while offering a lighter weight, smaller chassis and more efficient Class D power. The feature-rich design of the D1650 is ideal for the demands of distributed audio systems and is also compatible with our Russound volume controls.

Get to know this product.

More power, more efficient, more robust…just more. For nearly 50 years Russound has been designing equipment to fit an installer’s needs. When we went to redesign the next generation of our ubiquitous multi-channel amplifier line, we approached it from the ground-up. The result is the D-Series, a completely custom-built solution that has all the great features of our historically popular multi-channel amps in a much more refined platform.

The Russound D1650 digital multi-channel amplifier offers the features custom installation professionals demand while offering a lighter weight, smaller chassis and more efficient Class D power. The feature-rich design of the D1650 is ideal for the demands of distributed audio systems and is also compatible with our Russound volume controls. The D1650’s 16 channels are arranged in stereo pairs to provide discreet amplification and custom configurations for each of 8 zones.

Sound Quality

The D-Series amplifiers all have the same legendary Russound sound quality and installer-friendly features customers have come to expect. Ultra-low distortion output (relatively unheard of in other multi-zone amplifiers) allows for clean, undistorted audio even at high listening volumes. A robust protection circuit provides efficient, safe and reliable operation under extreme conditions and protects each amplifier output channel.

Home Theater

The D-Series amps are even up to the rigorous demands of home theater applications, easily transforming into a powerful 160 watt X 8 channel monster (in bridged mode). You can also choose to individually un-bridge pairs for lower power applications such as Dolby Atmos® or surround speakers. As an example you could run a Dolby Atmos 7.1.2 system at 7 channels @ 160W and 2 channels @ 50W. That’s Russound versatility!

Say “no” to the hum

Advanced triggering options allow the amps to operate on demand. Apart from the obvious energy efficiency, there is no amplifier hum on your speakers when the system isn’t in use.

High efficiency, cool running digital amplification

Zones are bridgeable to create flexible power configurations

Global bus input, independent inputs per zone

Global trigger input/output

Independent trigger input/output per zone

Audio sensing with auto-switching delay settings per zone

Robust protection circuitry for operation under extreme conditions

Rack mountable

Class-D power compatible with Russound volume controls

Specifications

General Specs

Impedance>22k Ohms Line Input
Channels16
Analog Audio(RCA) Input9

General

Shipping Dimensions21.5" (W) x 9.0" (H) x 22.0" (D), (54.6 x 22.9 x 55.9 cm)
Shipping Weight28.8 lbs (13.1 kg)
Amplifier Channels16 Channels, 8 independent zones
Bridge ModeSelect Stereo or Bridge mode per zone 8 Ohm only
Frequency Response20Hz to 20kHz +1.7/-1dB at 1W output into 8 Ohms
Fuse Rating100-120V/T5A, 250V US & Canada, 220-240V/T2.5A, 250V Europe
Input Impedance>22k Ohms Line Input
Input Sensitivity600 mV for 80W @ 1 KHz 4 Ohm One Zone; 700 mV for 50W @ 1 KHz 8 Ohm One Zone
Power Output80W /Channel, 1kHz into 4 Ohms, One Zone Driven; 50W /Channel, 1kHz into 8 Ohms, One Zone Driven; 160W, 1kHz into 8 ohms, Bridge
Signal to Noise Ratio>90dB A-weighted
Speaker Connection(s)Detachable speaker terminals support up to 14awg wire
Switching DelayThree settings, 5 Seconds, 5 minutes, 10 minutes
Trigger Input(s)Bus and Zone @12VDC
Zone Line InputLine or Bus select switch per zone
